Inline Visual Dispensing Machine for Large PCB Flexible Process

The FS700 Series Inline Visual Dispensing Machine is an advanced dispensing solution specifically developed for large-format PCB manufacturing and high-mix SMT production lines. One of the standout features of the FS700 Series is its dual-valve asynchronous mode: the two valves can operate independently to handle different adhesives or solder pastes—for example, dispensing red glue and solder paste simultaneously. This makes it ideal for complex multi-process production tasks such as adhesive bonding and solder paste deposition on the same PCB.

Core Advantages

• Dual-Valve Asynchronous Process: Two valves work independently, dispensing two different adhesives or materials in one pass.
• Flexible Single-Head Operation: Operators can run only one head when large-area coverage is needed without high cycle speed
• Supports Extra-Large Boards: Perfect for power battery modules, display panels, and industrial control boards.

Typical Applications

✔ Large-format PCB and FPC adhesive gluing
✔ Red glue + solder paste mixed process
✔ SMT underfill and flip-chip bonding
✔ Dam & Fill for MiniLED module assembly
✔ Tilted/angled dispensing for non-planar boards

Technical Specifications

Q&A

Q1: Can I use two different glues at once?
A: Yes! The FS700’s dual-valve asynchronous mode lets you run red glue and solder paste or any other two adhesives at the same time—reducing changeover time and increasing process flexibility.

Q2: How does the tilt function help?
A: The valve’s tiltable rotating head reaches angled edges or hard-to-cover areas, perfect for large or irregularly shaped boards.

Q3: What if I don’t need high speed?
A: Simply switch to single-head mode for maximum coverage. The large working area makes it easy to process big PCBs without sacrificing precision.

Q4: Is it easy to integrate with my SMT line?
A: Absolutely! It supports SMEMA, MES, and real-time monitoring, with automatic track width adjustment for different panel sizes.

Conclusion

For manufacturers needing flexible, high-precision, large-format inline dispensing with dual-valve multi-process capability, the FS700 Series is the perfect fit for modern SMT and PCB lines—helping you handle everything from simple red glue spots to complex solder paste patterns on oversized panels.
